Z32 GEARBOX PROGRESS
So after stripping third gear in the standard S14 gearbox at Hampton Downs earlier this year I have decided to install a Z32 300ZX gearbox. Sadly I missed catching the fantastic sounds on the GoPro as it ran out of battery minutes before. I picked up this box imported from Japan...
After some degreaser, sand blasting and aluminium cleaner I got it back in to this state.
Matt Lauder sent me one of his water jet cut 12mm steel Z32 to SR20 adapter plates.
I have sent the bellhousing of to have 12mm machined off the mounting face to suit the adapter plate. In the mean time I need to replace some corroded and perished parts, and pull the damaged box out.
I am planning to pull the engine out to mate everything together for the first time on the hoist rather than grappling with things trying to align them under the car. From experiences with the poor fitment of an early version custom cast W57 to 4AGE adapter bellhousing I installed in my AE86, I don't want a repeat. On the bright side I became very quick at pulling out Toyota gearboxes. Plus it gives me a chance to give everything the once over while it's out.
After some degreaser, sand blasting and aluminium cleaner I got it back in to this state.
Matt Lauder sent me one of his water jet cut 12mm steel Z32 to SR20 adapter plates.
I have sent the bellhousing of to have 12mm machined off the mounting face to suit the adapter plate. In the mean time I need to replace some corroded and perished parts, and pull the damaged box out.
I am planning to pull the engine out to mate everything together for the first time on the hoist rather than grappling with things trying to align them under the car. From experiences with the poor fitment of an early version custom cast W57 to 4AGE adapter bellhousing I installed in my AE86, I don't want a repeat. On the bright side I became very quick at pulling out Toyota gearboxes. Plus it gives me a chance to give everything the once over while it's out.
60 Percent
Could never justify the cost, but at 60% discount could not let this deal pass. Workshop is looking up, thanks to my awesome Wife :)
Shock Grind
Had some clearance issues to the shock. I always knew there was rubbing, but figured it was just tyre to guard contact...found out too late... ah well, now i just have an extra slot in the locking collar.
Blue Steel
Two S13 / 180sx cages completed ready for spraying... 180sx sunroof version and S14 / S15 versions next on the list.
Diff Diff
Two welded R32 diffs half way complete. I added a further 8 welds per diff in the holes on the opposite side to the ring gear for extra strength.
Taps Galore
I was worried that my engineer would not have the right tap for the job. Yee of little faith... drawer measures 1500mm long x 700mm deep. Just one of 10 drawers.
